This additive is designed to be used with Global DG to produce the textured finish found as original equipment on parts of some vehicles. Texture Additive D843 provides a matt, suede effect.

Preparation of Substrate:
Prepare metal and painted surfaces by flatting and cleaning with appropriate PPG cleaner. See substrate preparation guide in the Global Refinish System Product Manual for full process details.
Clean plastic surfaces with Bodykleen followed by D846 Degreasing Agent for Plastics and prepare with appropriate primer. See PPG Guide to Painting Plastics in the Substrate Preparation Section of the Global Refinish System Product Manual.

Mixing Ratios:

Mixing Ratios with Accelerated Hardener	Mixing Ratios with MS Hardeners
DG/D800 - 2 vol	DG/D800 - 3 vol
D863 Accelerated Hardener - 1 vol	MS Hardener - 1 vol
Thinner - 2 vol	Thinner - 2 vol
D843 - 2 vol	D843 - 3 vol

Application Guide:

	MS Hardener	Thinner
Up to 18'C	DH710 Fast	DT810 Fast
18'C - 25'C	DH720 Medium	DT820 Medium
Over 25'C	DH730 Slow	DT830 Slow

Application is as for Global DG or Global Clear.

Do not use in Global BC.

Ensure the Topcoat/Additive mixture are well mixed before adding Hardener.
